LLDPE 22501AA / LLDPE 22501KJ

Density: 0.922 - 0.924 Application: Blown film grade General Purpose opplications




Petrochemical: Jam

22501 is a LLDPE blown film grade designed for applications requiring good optical properties even at low extrusion temperature. This resin combines ease of processing with low gels and it is well suited for blending with LDPE and for general purpose applications.

LLDPE: LL22501AA | LL22501KJ

Characteristic Properties

High stiffness, good optical properties
Low extrusion temperature
Ease of processing, low gels
Suited for blending with LDPE

Density: 0.922 – 0.924

Additives

22501AA
Thermal Antioxidant (Process Stabilizer)
Catalyst neutralizer (acid scavenger, lubricant)
22501KJ
Thermal Antioxidant (Process Stabilizer), Antiblocking Agent, Slip Agent
Catalyst neutralizer (acid scavenger, lubricant)

  • Blown film grade:

  • General Purpose applications:

Resin Properties Unit Typical Value ASTM Method
Melt Index (190°C/ 2.16Kg) g/10 min 0.95 D1238
Density g/ml 0.923 D1505
Film properties @
Dart Impact g 70 D1709
Elmendorf Tear g MD/TD 105/436 D1922
Tensile Strength at yield MPa MD/TD 12-Nov D882
Tensile Strength at break MPa MD/TD 41/31 D882
Ultimate elongation % MD/TD 648/780 D882
Haze % 34 D1003
Gloss 45° 24 D2457
@ 25 micron film obtained on Collin 25, B.u.R. 2.5: 1, Temp. profile 155 190°C.
Recommended processing conditions
Melt Temperature °C 190-230
Blow up ratio 2.0-3.0
Die Gap mm 2.0-2.5
Thickness micron 15-150
